Products
RDS16S
Features
- Light and siren control with full feature siren
- 14 controlled outputs: 3@20Amp and 11@10Amp
- Radio re-broadcasting
- Park Kill
- All control outputs are solid state relays
- The touchpad includes 16 illuminated push button switches
- Traffic control indicator
- Operates one or two 100W speakers
- Meets SAE J1849
Literature / Downloads
If you have other questions please contact us or call 1-800-538-7338
Read more about our equipment in newsletter section
Technical specifications
Operating Current
10Amps
Frequency Range
700 to 1640Hz (nominal)
Input Voltage
11 to 16 Volts DC
Operating Temperature Ranges
-30oC to +65oC
Standby Current; 50mA +/- 10%
Cycle Rate
Wail - 17 cycles/min Yelp - 230 cycles/min Stinger - 1000 cycles/min
Nominal Output
52V p-p (11Ohm load)
Audio Frequency Response
100-4000Hz +/- 3dB
Audio Distortion
10% or less
Audio Power
32 watt
Input Impedance
600Ohm
